In this tutorial, I will show you the steps used to create this distorted lady figure effect in Photoshop. We will use metal and rock texture over a female body to create the main effect, and use various image adjustments, layer masks and filter to fine-tune the effect.

This is an intermediate level tutorial.

Note: The Photoshop tutorial is done in Photoshop CC – therefore some screenshot may have slighting different layout as in the earlier version. Some brushes are exclusive to Photoshop CS6.

Here is a preview of the final effect I have for this tutorial: (click to enlarge)

distorted lady manip flatten 474x700 Create Distorted Lady Figure Effect in Photoshop

PSD File Download

You can download the PSD File for this tutorial via the VIP Members Area for only $6.95/Month (or less)! You will not only get this PSD File, but also 100+ other PSD Files + Extra Goodies + Exclusive Photoshop tutorials there. Signup now and get exclusive :) Find out more about the VIP Members Areas

vip sign up 250 Create Distorted Lady Figure Effect in Photoshop

OK Let’s get started!

To complete this tutorial, you will need the following stocks:

Model by mariaamanda

Metal texture

Rock texture (image 1)

Step 1

Create a new document sized 800px * 1180px with black background. Load the rock stock image into Photoshop and select the following portion:

1 sel 550x368 Create Distorted Lady Figure Effect in Photoshop

Copy and paste the selection to our document, rotate it 90 degrees and re-size it to fit our canvas size. Use a soft eraser to fade the edges as shown below:

1 paste1 468x700 Create Distorted Lady Figure Effect in Photoshop

Use a solid eraser, dig some holes on the rock texture as shown below:

1 erase 2 464x700 Create Distorted Lady Figure Effect in Photoshop

Add the following levels adjustment layer on top:

1 lvs Create Distorted Lady Figure Effect in Photoshop

and here is the effect so far:

1 effect1 465x700 Create Distorted Lady Figure Effect in Photoshop

Step 2

We will work on the lady figure in this step. Load the model image into Photoshop and cut out the body, paste it over to our document as shown below. You will have to re-size the model layer to fit our canvas size.

2 paste1 490x700 Create Distorted Lady Figure Effect in Photoshop

Use a combination of soft and hard eraser, remove the edges of the body as shown below:

2 erase1 Create Distorted Lady Figure Effect in Photoshop

Add the following adjustment layers as clipping masks to this model layer:

Black and White

2 bw Create Distorted Lady Figure Effect in Photoshop

Layer mask (in red) on the black and white adjustment layer:

2 mask Create Distorted Lady Figure Effect in Photoshop

Levels

2 lvs Create Distorted Lady Figure Effect in Photoshop

Layer mask (in red) on the levels adjustment layer:

2 lvs mask Create Distorted Lady Figure Effect in Photoshop

and here is the effect so far:

2 effect1 Create Distorted Lady Figure Effect in Photoshop

Step 3

We will apply the metal texture over the model in this step. Load the metal stock into Photoshop and select a portion with Lasso Tool as shown below:

3 sel1 Create Distorted Lady Figure Effect in Photoshop

Copy and paste the selection to our document, set it as a clipping mask to the model layer (place it above all those adjustment layers in step 2). Apply the following Black and White adjustment to it:

3 bw Create Distorted Lady Figure Effect in Photoshop

Add the following layer mask (in red) to this metal texture layer to hide some parts:

3 mask 520x700 Create Distorted Lady Figure Effect in Photoshop

and here is the effect so far:

3 paste Create Distorted Lady Figure Effect in Photoshop

Change the layer blend mode of this metal layer to “color burn”:

3 col burn 550x418 Create Distorted Lady Figure Effect in Photoshop

and here is the effect so far:

3 effect Create Distorted Lady Figure Effect in Photoshop

Step 4

We will add some rock patterns to our image. Go back to our rock image and select the following portion on the top left:

4 se 550x206 Create Distorted Lady Figure Effect in Photoshop

Copy and paste the selection over to document and remove the edges as shown below with a soft eraser:

4 mask 550x298 Create Distorted Lady Figure Effect in Photoshop

Add the following adjustment layers to this rock texture layer:

Black and White

4 bw Create Distorted Lady Figure Effect in Photoshop

Levels

4 lvs Create Distorted Lady Figure Effect in Photoshop

Add some splatter brush effect around the rock, and here is the effect so far:

4 splatter 518x700 Create Distorted Lady Figure Effect in Photoshop

Step 5

We’re almost done! We can now flatten the image (make sure you save a layered copy just in case you want to go back to it later on), duplicate the background layer and apply the following Accented Edges filter to the duplicated layer:

5 accent edges Create Distorted Lady Figure Effect in Photoshop

and you will see this filter adds some extra black lines around the rock texture:

5 after ac 550x442 Create Distorted Lady Figure Effect in Photoshop

5 after ac 2 550x250 Create Distorted Lady Figure Effect in Photoshop

Add the layer mask onto this layer to reveal the background layer:

5 mask1 452x700 Create Distorted Lady Figure Effect in Photoshop

Step 6

I decided to add some colours to our image. To do this, let’s add the following adjustment layers on top:

Levels

6 lvs Create Distorted Lady Figure Effect in Photoshop

Layer mask on the levels adjustment layer:

6 lv mask1 467x700 Create Distorted Lady Figure Effect in Photoshop

Color Balance

6 col sha Create Distorted Lady Figure Effect in Photoshop

6 col mid Create Distorted Lady Figure Effect in Photoshop

Layer mask on the color balance adjustment layer

6 col mask 469x700 Create Distorted Lady Figure Effect in Photoshop

Curves

6 curvs Create Distorted Lady Figure Effect in Photoshop

Layer mask on the curves adjustment layer:

6 cur mask Create Distorted Lady Figure Effect in Photoshop

Vibrance

6 vib Create Distorted Lady Figure Effect in Photoshop

and here is my final effect: (click to enlarge)

distorted lady manip flatten 474x700 Create Distorted Lady Figure Effect in Photoshop

That’s it for this tutorial! Hope you enjoy going through it and find it useful. Drop me a comment below if you have any question.

Till next time, have a great day!
